Small objects count photoelectric sensor V5BF-100 / V5BF-102

Description

• The materials of the object are not limited (Plastic, metal and other opaque objects can be detected)
• Long service life of the sensor (Perfect design of special flexible cable and anti break structure)
• Extremely fast response time (The fastest response speed can be up to 1000 times per second without missing detection)
• High detection accuracy (Standard minimum object size is 0.5mm, special customisation 0.3mm)
• Dust stability (The built-in sensitivity compensation circuit enables the receiver to work normally even when the amount of light received is reduced due to dust)

‍Download documentation

‍

Smallest detectable object: diameter 0.5mm opaque object

Light source: Infrared LED

Sensitivity modulation: 1 circle knob fine-tuning regulator

Indicator: Output: Red LED; stable operation: green LED

Control output: NPN: maximum 100mA (maximum 40V), residual voltage: Max 1V

Reaction time: 0.2ms

Off time: 0.5ms

Delay function: 70ms (selectable)

Power: 12 to 24VDC±10%

Current Consumption: Max. 40mA

Ambient luminosity: filament lamp: maximum 10000lux; daylight maximum: 1500lux

Ambient temperature: Sensor head -10 to +50 Amplifier -10 to +50 no freezing

Relative humidity: 35 to 85% no condensation

Case material: Polycarbonate

Weight: Sensor head with 2m cable about 40g Amplifier( with 2m cable about 100g
