Ultrasonic edge sensor V5UN series

Product description

‍

Filling level and height sensing, interval measurement, coil diameter sensing, bottle counting, size measurement, material stacking height measurement, diameter and speed measurement, contour measurement, loop monitoring, quality inspection, distance monitoring, filling level measurement.

• The measurement is not affected by color, transparency, glossiness and ambient light
• Smaller blind area and longer detection distance can be as far as 4m
• With temperature compensation function and is not affected by ambient temperature
• With synchronous function, multiple sensors are close to each other side by side without mutual interference
• Strong anti-interference ability, enhance electromagnetic interference and radio frequency interference
• With NPN, PNP switch output, and 4-20mA, 0-10vdc analog output
• Completely free from dust, dirt and fog
• Ultrasonic sensors can be widely used in many fields

Download documentation

‍
